Factory Use X Ray Baggage Scanner With 500*300cm Tunnel For Quality Control

Product Categories
SHENZHEN SECURITY ELECTRONIC EQUIPMENT CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Factory Use X Ray Baggage Scanner With 500*300cm Tunnel For Quality Control

  • 1
  • 2
  • 3

Brand Name : SECUSCAN

Model Number : AT5030C

Certification : CE, ISO

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, L/C, Western Union

Supply Ability : 500 sets/month

Delivery Time : One week when there is stock, One month when no stock.

Packaging Details : Wooden Packing

Waranty : One year free spare parts, life technic support

Software Interface : Support Multi language

Training : Free training in the factory

Installation : very easy

Operatoin : User maual attached with machine

OEM/ODM : Accepted

Tunnel size : 500(W)*300(H)mm

Penetration : 30-32mm steel

Tube voltage : 140kv

Conveyor max load : 150kg

Contact Now

Factory Use X Ray Baggage Scanner With 500*300cm Tunnel For Quality Control

Specification

Contents

Index

Technical Data

Model Name: AT5030C

Tunnel Size: W500*H300mm

Conveyor Speed: 0.22m/s

Conveyor Max Load: 150 kg

Single Inspection Dosage: < =0.1µ GY

Resolution: 0.087mm metal line

Steel Penetration: typical 40mm steel

Film Safety: For ISO 1600

Maximum leakage radiation: <0.05µ GY/H

X-ray Generator

Orientation: Vertically Upward

Tube Current: 0.4~1.2MA(adjustable)

Anode Voltage: 140kv

Angle: 80°

Operating Environment

Storage Temperature: -20ºC to 60ºC

Operating Temperature: 0ºC to 45ºC

Relative Humidity: 20 -90%non-condensing

System Power: 220 VAC(±10%) 50±3HZ

Power wastage: 1.0KW (Max)

Noise: <55DB

Packing and Shipment:

Packing details

carton packing

1 set/ctn

Packing Size: (L)1850*(W)830*(H)1500mm

Gross Weight:500kg

Payment terms

T/T, Western Union, Cash,L/C

Shipping methods

By air (5-7days, most expensive)

By express (3-7days, more expensive)

By sea (15-28days, cheapest)

Applications:

End user Recommend X Ray Baggage Scanner model NO.
Airports, Transport terminals AT6040; AT6550; AT10080; AT100100
Factories (to find needle in clothing, shoes, bags), AT5030; AT6040; AT6550
Courthouses, Embassies, Buildings AT5030; AT6040; AT6550
Military installations AT5030;AT6040; AT6550; AT8065; AT100100
Prisons, Hotels, Schools, Convention centers AT5030; AT6040; AT6550; AT10080
Security checkpoints,Special events location AT5030; AT6040; AT6550; AT8065; AT10080

Company profile:

Rose,from Security Electronic Equipment Co.,Ltd(SEE) .

The biggest manufacturer of threats detecting device in South of China.
With professional R&D engineer team are specialized in:
  • Under vehicle inspection system(new)-mirror & camera
  • Explosive and Drug trace detection(new)
  • Dangerous liquid scanner(new)
  • X-ray screening system for baggage
  • Walk through metal detectors
  • Hand held metal detector
Quotation will send you by your inquiry ASAP
