Turn Key Security Airport Baggage Scanner For Middle Size Baggage Inspection

Brand Name : SECUSCAN

Model Number : AT6550

Certification : CE, ISO

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, L/C, Western Union

Supply Ability : 300 sets/month

Delivery Time : One week when there is stock, One month when no stock.

Packaging Details : Wooden Packing

Installation : very easy

Tunnel size : 650(W)*500(H)mm

Penetration : 30-32mm steel

Conveyor max load : 170kg

Conveyor speed : 0.22m/s

Anode voltage : 100-160kv

Film Safety : guarantee ISO 1600 film

OEM/ODN : Accepted

Warranty : One year free spare parts, life time technic support

Training : Free of cost at the factory

Contact Now

Turn Key Security Airport Baggage Scanner For Middle Size Baggage Inspection

Competitive Advantage:

  • Integrated, cost Effective, Turn-Key Security
  • Fit for small Baggage and Parcel Security Inspection.
  • Increased detection capability
  • Friendly interface for ease-of-use
  • Reliable performance and uncompromising value

Specifications:

Tunnel Size:

650(W)*500(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

170kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

34mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

100-160Kv

Anode power:

0.4 to 1.2mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic), 12bit Deep

Monitor:

High Resolution Color, LCD Accord, 17 inch

Image Processing:

Edge enhancement, image strengthening, image lightening,

reducing darkening, image returning, image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

Zones & Zoom:

1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.1 KW (max), 0.3KW(working)

Noise:

<58db

Applications:

  • Airports,
  • Transport terminals,
  • Buildings,
  • Factories (to find needle in clothing, shoes, bags),
  • Courthouses,
  • Embassies,
  • Military installations,
  • Prisons,
  • Hotels,
  • Schools ,
  • Convention centers,
  • Security checkpoints,
  • Special events location
