Steel Penetration 32mm Guaranteed Security X Ray Baggage Scanner

Brand Name : SECU PLUS

Model Number : SPX-8065

Certification : CE, ISO

Place of Origin : China

MOQ : 1

Payment Terms : L/C,T/T

Supply Ability : 300 sets/month

Delivery Time : 7 days when we have stock,15 days when we have no stock

Packaging Details : Wooden Packing

Warranty : 12 months

Technical Support : free of all life

OEM : Yes

Tunnel Size : 800*650mm

Penetration : 30 to 32mm steel

Film Leakage : Guarantee ISO 1600 Film

X-ray Leakage : <0.5μSv/h (at a distance of 5cm from external housing)

Conveyor Speed : 0.22m/s

Conveyor Max Load : 200kgs

Software interface : Support multi-language

Wire resolution : 32-38AWG

Spatial resolution : horizontal:1.3 or 1.0mm, vertical: 1.3 or 1.0mm

Pass rate : 720 bag/h

Price : Negotiable

Contact Now

Steel Penetration 32mm Guaranteed Security X Ray Baggage Scanner

Model: SPX-8065

Advantage:

Assist of detecting organic and inorganic items such as
weapons, explosives and narcotics using different color show

Quick Details

General Specification:

Tunnel Size: 800(W)*650(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 200kg
Wire Resolution: 32AWG to 38AWG
Spatial resolution: horizontal:1.3 or 1.0mm,
vertical: 1.3 or 1.0mm
Penetration: 30 to 32mm Steel
Film Safety: Guarantee ISO1600 Film
X-ray Leakage: <0.5 μSv/h (at a distance of 5cm
from external housing)
Pass rate: 720 bags per hour

Installation Data:

Operation temperature/Humidity: 0℃-45℃/20%-95%(non-condensing)
Storage Temperature/Humidity: -20℃-60℃/20%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz
Power Consumption: 1.0 KW (max), 0.7KW(working)
Noise: <58db

X-ray Generator:

Beam direction: Diagonal
Generate angle: 80 degree
Anode Voltage: 140Kv
Anode power: 0.35mA
Cooling / Duty Cycle: Oil Cooling /100%

Image System:

X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor: High Resolution Color, LCD Accord, 19 inch
Image Processing: Edge enhancement, image strengthening, image
lightening,, reducing darkening, image returning,image retrieval.
Image Grey Level: 4096
Image Processing: 24bit for processing real time
Image storage: Storage 60000 pictures in real time
Zoom: max 16 Times Enlarge, Whole screen continuous observation

Our service:

  1. Operation training program for end users
  2. Free of factory training for engineer from agents to end user
  3. Provide on-site trainning when customer requires
  4. If quality problems happen in guarantee period, our company will maintain for free.
  5. One year free spare parts and life time technical support
  6. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
  7. If you are caught in some problems when using our products, welcome to contact us at any time.

Steel Penetration 32mm Guaranteed Security X Ray Baggage Scanner

Steel Penetration 32mm Guaranteed Security X Ray Baggage Scanner
